Detailed information on the Kellys ARC 10

Rate Kellys ARC 10:

4.0/5 (3 votes)

Write a Review

Kellys ARC 10 Price

Not Available

Similar Road Bikes

Factor One SpongeBob Edition - Shimano Ultegra

Pinarello Dogma F 1K

Eddy Merckx Pevele Carbon Shimano GRX800 2x12sp

Brodie Ronin 1.0

Author Charisma 66i 2025-26

XDS X-Lab RT9

Specifications

Vehicle Type	Road Bike
Stem	KLS Active Road - diam 28.6 mm / bar bore 31.8 mm / 6° / length 70 mm (S), 90 mm (M), 110 mm (L)
Handlebar	KLS Expert Road - diam 31.8 mm / width 400 mm (S), 420 mm (M), 440 mm (L)
Fork	KELLYS Carbon / 1.5" tapered steerer
Seatpost	KLS Active - diam 30.9 mm / length 350 mm (S), 400 mm (M - L)
Grip	KLS bar tape
Crankset	SHIMANO Claris R2000 (50x34T) - length 170 mm (S - M), 175 mm (L)
Chain	KMC Z8
Shifters	SHIMANO Claris ST-R2000 Dual Control
Gear	16
Saddle	WTB Volt
Headset	FSA 1.5" semi-integrated
Derailleur : Front	SHIMANO Claris R2000 (braze on)
Derailleur : Rear	SHIMANO Claris R2000 (direct mount)
Hub : Front	SHIMANO Claris 2400 (32 holes)
Hub : Rear	SHIMANO Claris 2400 (32 holes)
Spoke	Stainless steel black
Cassette	SHIMANO CS-HG50-8 (11-32T)
Bottom Bracket	SHIMANO BB-RS500

Brakes
Front Brake	TEKTRO
Rear Brake	TEKTRO
Brake Lever	SHIMANO Claris ST-R2000 Dual Control

Chassis and Suspension
Frame	KELLYS Endurance Concept Aluminium alloy / 1.5" tapered HT, internal routing

Tyres
Wheels / Rim	Rim: KELLYS Spark 622x15 (32 holes / eyelets)
Front Tyre	SCHWALBE Lugano 25-622 (700x25C) K-Guard, Silica
Rear Tyre	SCHWALBE Lugano 25-622 (700x25C) K-Guard, Silica

Dimensions
Weight	10.16 kg
