Vehicle Type | Road Bike |
Stem | Onoff S3 6061 T6 Alloy, 31.8mm barbore, rise: -7º, length: S size: 60mm, M size: 70mm, ML size 70mm, L size: 80mm, XL size: 90mm |
Handlebar | OnOff S3 GR 16º bar flare. Width sizes S size: 440mm M size: 440mm ML size: 460mm L size: 460mm XL size: 460mm |
Fork | Stealth Air Carbon tapered steerer tube, HHG, flat mount integrated fork |
Seatpost | Onoff S9 Carbon 0-R, diameter 27.2mm, length 400mm |
Grip | OnOff HEX Bar tape |
Crankset | Shimano GRX RX-610, S size: 170mm M size: 170mm ML size: 172,5mm L size: 172,5mm XL size: 175mm, CL 49,7 |
Chain | Shimano SLX M7100, Quick link |
Shifters | Shimano GRX RX-610 dual control, alloy lever |
Saddle | FIZIK Terra Argo X5 140mm |
Headset | Onoff IS52/IS52, 1-1/8", 1.5" head tube, sealed bearings, Internal cable routing |
Derailleur : Rear | Shimano GRX RX-822-GS, 12s |
Hub : Front | Mavic, 12x100mm, IS 6 bolts |
Hub : Rear | Mavic infinity hub, 12x142mm, XD ID360 Ratchet system, IS 6 bolts, MS Freehub |
Spoke | Mavic Steel double butted flat spokes |
Cassette | Shimano SLX M7100, hiperglide+,10-45, 12s |
Chainrings | Shimano 40T, direct mount, steel |
Bottom Bracket | Token T47 BSA sealed bearings, 85,5mm |
Tyres |
---|
Wheels / Rim | Mavic Allroad Disc, UST, 25mm internal width, hookless, infinity hubs, 24 spokes front, 28 spokers rear |
Front Tyre | Maxxis Reaver 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead |
Rear Tyre | Maxxis Reaver 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead |
